Digital Multimeters

SIGLENT’s SDM3000 Series Digital Multimeters are dual-display multimeters offering 4½, 5½ and 6½-digit resolution with up to 35 PPM DCV accuracy and a powerful feature set at an excellent price.

Compare Models

Accurate and Powerful Full-Function Digital Multimeters

SDM3065X Digital Multimeter

SIGLENT digital multimeters are dual-display digital desktop multimeters that provide a rich and powerful feature set at an excellent price. This DMM family is well suited for production testing, R&D and certification work, as well as any place where an accurate and powerful full-function DMM is needed.

The design is easy-to-use from the front-panel and computer-based control via USB or LAN. Equipped with a 4.3 inch TFT-LCD true color screen with 480 * 272 resolution for easy viewing. The digital multimeters also feature numerical data display, histograms, trend charts, bar charts and statistics, in addition to the built-in arithmetic functions including measurement statistics. SIGLENT digital multimeters are accurate, reliable, and dependable.

On-screen Trend Chart

Digital multimeters observe measurements vs. time

On-screen Statistics

Quickly obtain standard deviation and more with DMMs

Multi-Channel

Multi-channel scanner models available (SDM3055 and SDM3065X with SC1016 option only)

Series Reading Resolution DC Voltage Accuracy in a Year DC Voltage Measurement Range AC Voltage Measurement Range DC Current Measurement Range Price
SDM3065X 6 1/2 0.0035 + 0.0006 200 mV to 1000 V 200 mV to 750 V 200 µA to 10 A $745 - $995
SDM3055 5 1/2 0.015% 200 mV to 1000 V 200 mV to 750 V 200 µA to 10 A $499 - $745
SDM3045X 4 1/2 0.01% 600 mV to 1000 V 600 mV to 750 V 600 µA to 10 A $399
