SNA6000A Vector Network Analyzer

  • Frequency Range: 100 kHz to 13.5 GHz and 100 kHz to 26.5 GHz
  • Range of IFBW: 1 Hz to 10 MHz
  • Dynamic Range: 135 dB
  • Setting Range of Output Level: -55 dBm to +10 dBm
  • Standard Bias-Tee connection and pulse hardware
  • 4-port models include standard second source
  • Jumpers / DRA (Source, Ref and Meas) standard on SNA61xxA models

Product Overview

The rapid development of radio technologies increases the need for high-performance measurement technology. The SNA6000A series meets these requirements with impressive specifications and numerous useful, powerful functions. The SNA6000A series represents a versatile, powerful and user-friendly solution for the measurement and analysis needs in modern electronics. The series contains a total of eight models, which are available in bandwidths of 13.5 GHz and 26.5 GHz. Both a 2-port and a 4-port model are available for each bandwidth. All models are available in both a standard version and an extended version with Direct Receiver Access (DRA). SNA6000A is based on a flexible and integrated system which provides high performance and future proofs the platform for future expansion and innovation.



Series Frequency Range Ports Dynamic Range Trace Noise Range of Output Price
SNA6034A 100 kHz to 26.5 GHz 4 135 dB 0.005 dB rms, 0.012° rms -55 dBm ~ +10 dBm $62,386 Buy Now
SNA6032A 100 kHz to 26.5 GHz 2 135 dB 0.005 dB rms, 0.012° rms -55 dBm ~ +10 dBm $47,216 Buy Now
SNA6024A 100 kHz to 13.5 GHz 4 135 dB 0.005 dB rms, 0.012° rms -55 dBm ~ +10 dBm $51,796 Buy Now
SNA6022A 100 kHz to 13.5 GHz 2 135 dB 0.005 dB rms, 0.012° rms -55 dBm ~ +10 dBm $37,636 Buy Now
SNA6134A 100 kHz to 26.5 GHz 4 135 dB 0.005 dB rms, 0.012° rms -55 dBm ~ +10 dBm $72,386 Buy Now
SNA6132A 100 kHz to 26.5 GHz 2 135 dB 0.005 dB rms, 0.012° rms -55 dBm ~ +10 dBm $52,216 Buy Now
SNA6124A 100 kHz to 13.5 GHz 4 135 dB 0.005 dB rms, 0.012° rms -55 dBm ~ +10 dBm $61,796 Buy Now
SNA6122A 100 kHz to 13.5 GHz 2 135 dB 0.005 dB rms, 0.012° rms -55 dBm ~ +10 dBm $42,636 Buy Now

Key Features

  • Frequency Range: 100 kHz to 13.5 GHz and 100 kHz to 26.5 GHz
  • Number of Points: 2 to 100,001
  • Frequency Resolution: 1 Hz
  • Level Resolution: 0.05 dB
  • Range of IFBW: 1 Hz to 10 MHz
  • Dynamic Range: 135 dB
  • Setting Range of Output Level: -55 dBm to +10 dBm
  • Noise Floor: -135 dBm/Hz, 8 GHz to 20 GHz
  • Standard Bias-Tee connection and pulse hardware
  • 4-port models include standard second source
  • Jumpers / DRA (Source, Ref and Meas) standard on SNA61xxA models
  • Interface: LAN, USB Device, USB Host (USB-GPIB)
  • Remote Control: SCPI / Labview / IVI based on USB-TMC / VXI-11 / Socket / Telnet / WebServer

Need more information? Call us now 877-515-5551

Product Characteristics

High Dynamic Range and Precision View more

High Dynamic Range and Precision

High Dynamic Range and Precision

High dynamics enable more precise and reliable measurements, which is of great importance in research, development and production. The SNA6000A impresses with a dynamic range of over 135 dB, which makes it ideal for the detailed analysis of weak signals, even when they occur alongside stronger signals. This makes the analyzer ideal for measuring filters with low insertion loss and high stopband attenuation. In addition, high dynamics help to minimize signal distortion, which improves signal integrity. It also increases calibration accuracy, especially in scenarios where external influences such as cables or adapters must be minimized.

Spectrum Analyzer for Component Characterization View more

Spectrum Analyzer for Component Characterization

Spectrum Analyzer for Component Characterization

The integration of a spectrum analysis function into a vector network analyzer (VNA) opens up expanded possibilities, especially in the development and testing of high-frequency amplifiers, oscillators and communication systems. This extension is also available as an option namely SNA6000-SA. It allows precise analysis of harmonics, intermodulation products and other nonlinear effects, while simultaneously optimizing signal quality and bandwidth utilization in communication applications. The combination of VNA and spectrum analysis in one device not only offers space and cost-saving advantages, but also enables deeper and more comprehensive signal characterization.

Simple, Fast and Accurate Pulsed-RF Measurement View more

Simple, Fast and Accurate Pulsed-RF Measurement

Simple, Fast and Accurate Pulsed-RF Measurement

The SNA6000A can also be extended to include the ability to perform pulsed measurements, which is particularly advantageous when characterizing high-frequency components under real operating conditions, such as in radar and communication systems. This measurement method makes it possible to analyze the behavior of components with short pulses, precisely evaluate fast switching operations and optimize performance in time-critical applications.

Advanced Calibration View more

Advanced Calibration

Advanced Calibration

Calibrating network analyzers is critical for high accuracy measurements. The SNA family supports a broad range of mechanical and electronic calibration kits with the frequency up to 26.5 GHz for both general purpose and precision-level requirements and offers advanced calibration methods to enhance ease-of-use while providing best-in-class accuracy. SIGLENT protects your investment by supporting the import of calibration kits from other manufacturers and customer-defined calibration kits.

Time Domain Analysis View more

Time Domain Analysis

Time Domain Analysis

To be able to perform time domain analysis the options SNA6000-TDA and SNA6000-TDR are available. The Time Domain Reflectometry functions extend the VNA to include the ability to comprehensively diagnose and characterize signal paths, lines and cables. In addition, eye diagrams can be created, which are crucial for evaluating signal integrity in digital communications. The combination of TDR and VNA also enables the analysis of jitter, which is essential for investigating the temporal stability of signals. Both functions are of particular interest in high-speed digital development.

Extend the Power to Multiport Devices View more

Extend the Power to Multiport Devices

Extend the Power to Multiport Devices

SSM single unit can expand the output ports to 24 and can be easily integrated, greatly adapt to the automatic test system and production line scenarios. The multi-port measurement capability of VNA can improve test throughput and thereby significantly reduce device test costs. Typical applications include design, verification and production of antenna, data converter interfaces, automatic test of RF components and other devices, etc.
